Tesi NELLI EVH Style 16MM Momentary LED Push Button Guitar Kill Switch - Red

THIS LISTING IS FOR THE 16MM NELLI EVH STYLE KILL SWITCH WITH LED

Specs:

• Type: Momentary Push Button Switch
• Operation Type: Normally Open (yes, this is correct for instrument kill switch operation. Included instructions show you how to wire it properly!) Can be wired as Normally Closed upon request.
• Housing Material: Plastic
• Mounting hole Size: 16mm
• Mounting Panel Thickness: 1mm-6mm
• Operation Pressure: about 5n
• Operation Stroke: about 3mm
• LED Rated Voltage:  6V (includes wires to use with 9V battery and additional resistors in case you want to get creative with the wiring)
•           *note:  This will also function with an 18v active electronics system. Please make a note on your order to make sure you get the right resistors.
• LED Life: About 40,000 hours
• LED Power Draw: 15mA
• Contact Resistance: <50 mOhm
• Mechanical Life: 1,000,000 cycles
• Switch Rating: 3A/36VDC

What does all this mean?  You're getting a tough switch that will last a long time in your instrument and look good doing it!

The switch is easy to install. If you have the slightest bit of skill with a soldering iron you can do it yourself. If you do not have that skill, you should have a guitar repair person do it.

This package comes with everything:

• (1) Tesi NELLI 16mm Momentary Guitar Kill Switch - This is the size used on the Wolfgang Tour Guitar.
• (1) Tesi Quick-Connect wiring Bundle that includes:
•      (1) Black/Black ground wire
•      (1) Black/White hot wire
•      (1) 9V Battery Harness with 330 Ohm resistor
•      (1) On/Off Rocker Switch
• (1) Set of easy-to-follow wiring instructions
• (1) Spare 270 Ohm resistor for custom wiring jobs

When used with active pickups and/or a stereo output jack (not included) the Tesi NELLI does not require the included on/off rocker switch.

Each Tesi Guitar Kill Switch is guaranteed against defect for one year from the date of sale.  Contact us for more details.

The Tesi Switch Difference:

We test every switch before packaging it.  As a result, the failure rate is less than 1%.  We package the 12MM and larger switches in a custom cut foam block and place in a small box for protection.

PLEASE NOTE: Do not try to connect the switch directly to a battery. The LED is a 6V bulb and requires a resistor with a minimum value of 270 Ohms to work with a 9V battery.  Using a 9V battery without the resistor voids the warranty on the switch.
